Meter Panel
Meter Panels Are Used To House KWH Meter For Monitoring Or Billing Purpose From Utility Supply Provider Or End User. These Panels Are Available In Customizable Sizes To Suit Any KWH Meter Available. In High Rise Apartment Complexes Or Cluster Commercial Establishments, Meter Panels Are Used For Centralized And Easy Meter Reading And Billing. These Panels Are Generally Approved By The Electricity Authorities And Involve Sealing Of Compartments In Such A Manner That Power Theft Is Rendered Impossible.
- Available In 6, 9, 12 , 24 Way Meter Panels
- Available With Or Without Panel Isolators
- Pre-Punched For All Incoming And Outgoing Cabling
- 8 Pre-Drilled Holes For Easy Mounting
- Economically Priced
- Fast And Convenient Installation And Wiring
| Reference standard | IEC : 61439-1, IS : 8623 |
|---|---|
| Operational System | 415VAC 3 phase, 3 or 4 wire, 50 Hz |
| Operational current | up to 1800A |
| Degree of protection | IP-43 (indoor)/ IP-65 (outdoor) |
| Max. Temp. Rise | 40°C over ambient temp 45°C |
| Busbar | EC grade Copper or Aluminium |
| Form of separation | 2B |
| Operational height | 300-1800 mm |
| Max. Height of panel | 2175 mm |
| Cable Alley width | Minimum 300 mm |
| Depth of Panel | Up to 400 mm |
- Residential Complexes
- Cluster Commercial Establishments
- Townships
